Products Description
ADVANTAGES
1. Light weight, high strength, 50years durable use, no construction waste.2. Quality certification ISO: 9001: 2008
3. Cost considering: Time saved, cost saved;
4. Easy move, materials can be recycled used, environmentally;
5. Used widely, used as factory, warehouse, office building, aircraft hangar etc;
6. Structural durabilities, easy maintenance.
steel structure building is a new form in building construction, which is made from the organized combination of custom-designed structural steel members to meet architecture and engineering requirements of users. Steel structure involves sub-structure or members in a building made from structural steel,linked and fixed by welding, bolts and rivets.
| Application | Characteristic |
| Steel structure workshop High rise steel structure building Steel warehouse Large span steel frame Steel bridge Airport hanger Exhibition hall Gym shed Office building Poultry house Multi-storey building Storage shed | High strength Light dead load Good plasticity and toughness Easy fabrication High accuracy Save 65% of construction time Large span Space flexible Reduce construction waste and noise 98% steel components can be recycled, Environmentally friendly |
If you are interested in a structure for commercial or industrial use we've got you covered!
Because we custom build all of our structures we can make your virtually as large as you need with the specifications.
| Dimensions | Length | H beam: 4000-15000mm |
| Thickness | web plate: 6-32mm | |
| wing plate: 6-40mm | ||
| Height | 200-1200mm | |
| Color | According to customers | |
| Size | MOQ is 200 m2, width * length * eave height, | |
| Main components | Base | Cement and steel foundation bolt |
| Main frame | H beam | |
| Material | Q235B, Q345B or others as buyers' requests. | |
| Purlin | C or Z purlin: Size from C120~C320, Z100~Z20 | |
| Bracing | X-type or other type bracing made from angle, round pipe | |
| Bolt | Plain bolt and High-strength bolt | |
| Roof & wall | Sandwich panel or color plate | |
| Door | Sliding or rolling door | |
| Window | Aluminium alloy window | |
| Surface | Two times of Anti-rust Painting or Hot Dip Galvanized | |
| Sheet | 0.5mm or 0.6mm galvanized sheet | |
| Accessories | Semi-transparent skylight belts, Ventilators | |
| down pipe, galvanized gutter, etc |
| ABOUT XINBAOCHENG |
Linyi Xinbaocheng was established in 2005 in Linyi China, specialized in design, fabricate and erect of steel buildings. Consisting of a highly operate workshop, an experienced drawing office and an efficient erection team, Ridge Steel Buildings has the ability to provide customers for various steel building with reliable quality and good price.
| COUNTRY | TYPE | SIZE |
| Philippine | Fruits processing workshop | 4982m2 |
| Canada | Storage shed | 750m2*6 |
| Canada | Riding area | 600m2 |
| Malawi | Sawmill workshop | 2160m2 |
| Germany | Steel hall | 300m2 |
| Mauritius | Steel warehouse | 1116m2 |
| Zambia | Steel structure building | 1383m2 |
| XINBAOCHENG'S SERVICE |
Our team of steel structure design experts work with you to define your project balancing scope and budget. Within that process we will provide scope drawings, budget confirmation, and schedule. Each building is customized to provide lasting, maintenance-free value.
ENGINEER
After your design is finalized it is submitted to engineering. The engineering team will evaluate the structure to ensure it meets the design criteria and local code requirements. Once complete they will prepare final drawings and ready the plans for fabrication.
FABRICATE
steel buildings come pre-cut, pre-drilled, and ready for onsite assembly. Our fabrication process ensures the fabricated materials are cut to specification, packaged ready to for delivery by ship.
DELIVER
Before a building is delivered our logistics professionals will verify bill of materials quantities at the factory.
SUPPORT
We fabricate all structures to be erected on site by yourself or a professional. Regardless, our project management team will be ready to support you through completion until the last piece of trim is installed.
Product information
| Specifications | |
| 1)Size(m): | Width * Length * Height; |
| 2)Type: | Single slope, double slope, Multi-slope; Single span, double-span, Multi-span; Single floor, double-floor, Multi-floor; |
| 3) Base: | steel foundation bolts |
| 4) Steel frame: | Material Q345(S355JR)(Gr50)or Q235(S235JR) steel; Straight cross-section or Variable cross-section; steel welded H section painted or galvanized. |
| 5) Bracing: | X-type or V-type or other type bracing made from angle, round bar, etc ; |
| 6) Wall & Roof Purlin: | C section channel or Z section channel ,Size from C80~C300; Z100~Z300; |
| 7) Roof & wall cladding | Single color corrugated steel sheet 0.326~0.7mm thickness; Sandwich panel with EPS, ROCK WOOL,GLASS WOOL, PU etc insulation, thickness around 50mm 75mm 100mm 120mm 150mm 200mm; recommend coating PVDF SMP HDP PE |
| 8)Window: | UPVC/PVC or Aluminum Alloy window frame with glass. |
| 9)Door: | Exterior door:Sliding or Roller shutter door. Internal door:50mm thickness EPS sandwich panel with an aluminum alloy door frame |
| 10) Gutter material: | Color steel sheet or galvanized steel or stainless steel; |
| 11)Rainspout: | PVC pipe |
| 12)Connection | high strength bolts ,intensive bolt,self-drilling screws. |
| 13)Accessories: | Skylight panel, Ventilation, Fasteners etc |
| 14)Surface process: | Shot blasting Sa2.5;Two layers of Anti-rust Painting or galvanized |
| 15) Packing: | Main steel frame without packing load in 40' GP, roof and wall panel load in 40' HQ |
Checking Cost Of steel structure, Please Give Us The Information
(1) Dimension: Length, width, height, eave height, roof pitch, etc.
(2) Doors and windows: Dimension, quantity, position.
(3) Local climate: Wind speed, snow load, seismic magnitude etc.
(4) Insulation material: Panel type, sandwich materials, sandwich thickness
(5) crane metal structures: if have overhead crane, please tell the lifting height and lifting weight.
(6) Is there any materials that are not allowed to import to the country where the structure is planning to use?
(7) If you have other requirements, such as fire proofing, insulated roof, etc. Please also inform us.
(8) It's better if you have your own drawings or pictures. Please send them to us.
