Products Description
1. Products scope of using: 2. Structural Steel Buildings' Advantages: 4. the processing of the material
---Industrial steel structure warehouse / storage
---Steel workshop / factory
---light steel villa / prefab house
---hangar/garage/chicken shed,
---all kinds of steel materials . such as :
---1). sandwich panel , single steel sheet.
---2).welded H steel, C/Z channel
---3).Corrugated steel sheet.
---4).Purlin , floor deck and so on.
--- Easy Installation
--- Cost effective
--- Environmentally Friendly
--- Energy Savings
--- Safe and resistant
--- Improved construction quality
--- resist wind and earthquake
--- heat and sound insulation
--- No building garbage
--- Durability
3. Material list for steel structure building
Material List For steel structuture building Main Steel Frame Steel column Fabricated by Q235 or Q345 Steel, 80*80 or 100*100 or 120*120 or 150*150 Square Tube, alkyd paiting, two primary painting, two finish painting. Triangular Steel structure roof Fabricated by Q235 or Q345 Steel, C80, C100, C120, C140 Section steel, alkyd paiting, two primary painting, two finish painting. Roof Purlin Fabricated by Q235 Steel, C80, C100, C120, C140 Section steel, alkyd paiting, two primary painting, two finish painting. anchor bolt 10.9S, Galvanized Roof and Wall Roof Panel A: Insulated Steel Sandwich Panel wall
(1) Panel width: 950mm;
(2) Thickness: 50-1200mm.
(3) Powder coated Color steel on both sides: 0.4mm/0.5mm/0.6mm
B: Insulation: Polystyrene, Rockwool, Fiber Glass or Polyurethane
(1) Density of Rockwool: 50Kg/m3 ,80Kg/m3,100Kg/m3
(2) Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3
(3) Density of Polyurethane: 40Kg/m3
(4) Density of Fiber Glass:40Kg/m3, 60Kg/m3Wall Panel A: Insulated Steel Sandwich Panel wall
(1) Panel width: 950mm;
(2) Thickness: 50-1200mm.
(3) Powder coated Color steel on both sides: 0.4mm/0.5mm/0.6mm
B: Insulation: Polystyrene, Rockwool, Fiber Glass or Polyurethane
(1) Density of Rockwool: 50Kg/m3 ,80Kg/m3,100Kg/m3
(2) Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3
(3) Density of Polyurethane: 40Kg/m3
(4) Density of Fiber Glass: 40Kg/m3, 60Kg/m3Edge Cover 0.4mm galvanized color steel , angle Alu. Fasteners & Accessoreis Nailsglue ect Ceiling&Flooring Ceiling 6mm gypsum board,with steel keel Door and window Door Sliding door ,roller shutter door ,side hung door Window aluminum alloy window Plumbing System and Rain Water Drainage System as per building design
